Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyzers, m...
Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Structure： High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplication:We also have motors dia from 10-50mm,applications as followings for your reference:Robots, power tools, machinery, sanders, medical equipment, seat drives, automatic curtains, valves, electric surgical screwdrivers, medical analyze...
Sandard Parameters: MOTOR DATANominal Values1. Nominal voltage24 V2. No load current0.015 mA3. No load speed13000 rpm4. Nominal speed10910 rpm5. Nominal torque / Max continuous torque9.09mNm /28.42mNm6 .Nominal current (continuous current)0.525A7. Stall torque56.84 mNm8 .Stall current3.200 A9.Rated efficiency82.50%10 .Max speed14400rpmCharacteristics11. Terminal resistance7.5 Ohm12. Terminal inductance…… mH13 .Torque constant17.763mNm/A14 .Speed constant541.6rpm/V15. Rotor inertia…gcm216 .Ambient temperature-20/+60°C17. Max winding temperature120°COther Specifications18 .Number of pole pairs119 .Number of commutator segments520. Weight of motor42.4 g21. Level of noise65 dBAMax Efficiency Point22. Torque3.69 mNm23. Speed12155 rpm24. Cur...
Drawing:Bare metalEncoder1725 Encoder allows the motor with precise controllability, small size, can be widely cited in the medical machinery, beauty equipment, precision instruments and so on.Quality of products with a reliable warranty, we have a professional customer service 24 hours online, 100% service quality, the purchase of Hollow Cup motor is your wise choice.FAQ:Q: Can you provide me samples?A: Yes, we will give you a sample, if you need it, but you have to pay shipping and sample fees.Q: Can you design for me?A: We have experienced designers, and we can add your company logo, website, phone number or your idea on the carton according to your request ... Just give me your thoughts and let us you do.Why choose us?Advanced & Sufficient production equipments. Deliver Shippi...
