Specification of 1725Applications:This type can be used Rotary Tattoo machine, not only used of Key electronic cutting device, but also household hand tools, E-Drive coreless motors are widely used in Golfcaddy, Tattoo Eyebrow Machine,Beauty Apparatus,Medical Equipment,Robotics,Electric-drive curtain,Model Toys,Power Tools,Factory Automation & Robitics,Beauty Massage Products,Safety Engineering,Tattoo machine,Dental Instruments,Massage Instrument,Facial Cleansing Instrument, Adult Products etc.Structure: High quality copper wire Imported bearings from Japan Sturdy coils after high temperature and high pressure treatment High quality permanent magnet Wear resis...
Structure: High quality copper wire Imported bearing form Japan Sturdy coil after high temperature and high perssure treatment High quality permanent magnetWear resistant metal shaft High quality plastic back coverCertificates: ISO9001 CERTIFICATE SGS CERTIFICATE ROHS CERTIFICATE CUSTOMERS PRAISE MAILApplications:We also have motors dia from 10-50mm,applications as followings for your reference:Dental equipment, drone, medical equipment, tattoo machine, tattoo pen, beauty pen, electronic lock, scar treatment instrument, nail gun, blood analyzer, electronic door lock, power t...
-Small compact size and Light weight-No iron losses,high efficiency,long motor life-Low noice and high reliability-Widely used in Semi Permanent,Tattoo,A-MST Skin Care,Medical Equipments,Security Control,Measuring Instruments,Robotics,Power Tools,Golf cart, Industry Automation,Linear Actuator,Toy Model,Message,Sex Products,Electric Toothbrush,Electric Make-up Puff,Eyecare Massager,Facial Cleaning Apparatus,Precise Struments,Aeromodelling,Quadrocopter,UAV etc.-Customized Specifications are welcome!-We can accept OEM/ODM service.-Option Gearbox or Encoder as per your request.Typical Application:From automation to household hand tools,E-Drive coreless motors are widely used in Golfcaddy,Tattoo Eyebrow Machine,Beauty Apparatus,Medical Equipment,Robot,Electric-dribe curtain,Model Toys,Power Too...
DrawingStandard Parameters 2230 Series3612152440Rated Voltage3612152440VArmature Resistance0.6310.82150193ΩMax Output3.692.943.272.632.822.01WMax Effect797879787774%No-load Speed960093009500840090008200RPMNo-load Current0.090.0690.060.0570.0550.053ALocked-rotor Torque14.712.113.211.9129.37mNmFriction Torque0.120.120.120.120.130.14mNm
